型号 |
频率(GHz) |
频率(GHz) |
中心频率 |
带宽 |
隔离度 |
插入损耗 |
驻波比 |
功率 |
IMD |
|
---|---|---|---|---|---|---|---|---|---|---|
H103CZ6.05G | 6.025 | 6.080 | 6.0525 | 0.055 | 22 | 0.3 | 1.17 | 50 | -60 | |
H103CZ5.94G | 5.925 | 5.950 | 5.9375 | 0.025 | 22 | 0.3 | 1.17 | 50 | -60 | |
H103CZ5.5G-A | 5.150 | 5.925 | 5.5375 | 0.775 | 22 | 0.35 | 1.17 | 50 | -60 | |
H103CZ4.7G | 4.400 | 5.000 | 4.7000 | 0.600 | 20 | 0.4 | 1.17 | 50 | -60 | |
H103CZ4.5G | 4.400 | 5.000 | 4.7000 | 0.600 | 22 | 0.35 | 1.17 | 50 | -60 | |
H103CZ3.6G | 3.400 | 3.800 | 3.6000 | 0.400 | 20 | 0.3 | 1.22 | 50 | -60 | |
H103CZ3.5G | 3.400 | 3.600 | 3.5000 | 0.200 | 22 | 0.3 | 1.17 | 50 | -60 | |
H103CZ2.6C | 2.486 | 2.700 | 2.5930 | 0.214 | 22 | 0.3 | 1.17 | 50 | -60 | |
H103CZ2.6B | 2.545 | 2.665 | 2.6050 | 0.120 | 27 | 0.3 | 1.12 | 50 | -68 | |
H103CZ2.6G | 2.545 | 2.665 | 2.6050 | 0.120 | 25 | 0.25 | 1.12 | 50 | -60 | |
H103CZ2.3A | 2.260 | 2.440 | 2.3500 | 0.180 | 25 | 0.3 | 1.11 | 50 | -68 | |
H103CZ2.3G | 2.300 | 2.400 | 2.3500 | 0.100 | 20 | 0.3 | 1.17 | 50 | -60 | |
H103CZ2.2G | 2.250 | 2.280 | 2.2650 | 0.030 | 23 | 0.25 | 1.15 | 50 | -62 |
