Model |
Frequency(GHz) |
Frequency(GHz) |
Center Frequency |
Bandwidth |
Isolation |
INS LOSS |
VSWR |
Power |
IMD |
|
---|---|---|---|---|---|---|---|---|---|---|
HYG836AZ[10-15GHz] | 10.000 | 15.000 | 12.5000 | 5.000 | 20 | 0.4 | 1.25 | 10 | - | |
HYG836AZ[10.7-11.7GHz] | 10.700 | 11.700 | 11.2000 | 1.000 | 20 | 0.35 | 1.25 | 10 | - | |
HYG836AZ[7.7-8.5GHz] | 7.700 | 8.500 | 8.1000 | 0.800 | 20 | 0.3 | 1.25 | 10 | - | |
HYG836AZ[7.1-7.9GHz] | 7.100 | 7.900 | 7.5000 | 0.800 | 20 | 0.3 | 1.25 | 10 | - | |
HYG836AZ[6.4-7.2GHz] | 6.400 | 7.200 | 6.8000 | 0.800 | 20 | 0.3 | 1.25 | 10 | - | |
HYG836AZ[5.7-6.5GHz] | 5.700 | 6.500 | 6.1000 | 0.800 | 20 | 0.3 | 1.25 | 10 | - |
